N640 – ABB PCM600 Training

Master ABB Relays with Confidence

Learn how to configure, manage, troubleshoot, and commission ABB protection relays using PCM600 through practical, step-by-step demonstrations and real engineering projects.

Whether you are a protection engineer, commissioning engineer, automation engineer, or maintenance specialist, this course will help you gain confidence in working with ABB IEDs, IEC 61850 configurations, application logic, protection functions, and relay communication.

Course Code: N640
Course Type: Video-Based (Pre-Recorded)
Trainer: Dr. Saeed Roostaee
Language: English
Course Creation: November 2019
Last Updated: December 2025
Training Duration: 12.5+ Hours
Access: Lifetime Access + Future Updates
Certificate: Included
Technical Support: Included

Why Take This Course?

ABB PCM600 is one of the most widely used engineering tools for configuring and managing ABB protection and control relays.

Many engineers struggle with:

Installing PCM600 and connectivity packages
Creating and managing projects
Configuring protection functions
IEC 61850 integration
Disturbance records and event analysis
Application configuration and logic design
Commissioning and troubleshooting ABB relays

This course provides practical guidance and real-world examples to help you perform these tasks efficiently and confidently.

What You Will Learn

By the end of this training, you will be able to:

✔ Install PCM600 and Connectivity Packages

✔ Create and manage ABB relay projects

✔ Configure ABB protection relays

✔ Build IEC 61850-based plant structures

✔ Configure hardware and analog inputs

✔ Configure protection functions

✔ Work with Application Configuration Tool

✔ Configure Signal Matrix and Logic

✔ Configure GOOSE Messaging

✔ Configure IEC 61850 Reports (Client-Server)

✔ Manage firmware and software packages

✔ Analyze disturbance records

✔ Monitor relay signals and events

✔ Upload and download configurations

✔ Work online with ABB IEDs

✔ Use XRIO files and parameter settings

✔ Configure distance protection functions

✔ Configure earth fault and directional protection

✔ Perform maintenance and troubleshooting activities

Who Should Attend?

This course is ideal for:

Course Structure

Prerequisite Training A (55 Minutes)

Before starting the main training, participants receive introductory lessons covering:

Prerequisite Training B (80 Minutes)

Practical PCM600 workflow demonstrations:

Main Training Program

Part 1 – Introduction & Project Creation

Part 2 – Hardware Configuration & Logic Design

Hardware configuration
Current and voltage inputs
Function blocks
IEC 61850 naming conventions
ANSI device functions
Simple overcurrent protection configuration

Part 3 – Distance Protection Configuration

Part 4 – Earth Fault Protection & Disturbance Reports

Directional Earth Fault (67N)
Disturbance Recorder configuration
ARDAR
BRDAR
LED configuration

Part 5 – Parameter Setting & XRIO

Parameter settings
XRIO export and import
Settings management
Configuration verification

Part 6 – Working with Preconfigured Distance Relays

Part 7 – Advanced Protection & Logic Functions

Bonus Updates Included

March 2022 Update

Working Online with ABB Relays

Online relay communication
Testing protection functions
Practical demonstrations

August 2023 Update

Additional PCM600 Tutorials:

Supplementary Files Included

This course includes a large collection of practical resources:

These resources are designed to support both learning and real project implementation.

Benefits You’ll Gain

✔ Reduce commissioning time

✔ Improve relay configuration accuracy

✔ Learn proven engineering workflows

✔ Gain confidence working with ABB IEDs

✔ Improve troubleshooting skills

✔ Better understanding of IEC 61850 integration

✔ Access practical examples and reusable project resources

✔ Lifetime access to future course updates

Certificate of Completion

Participants who complete the training will receive a Certificate of Completion.

Technical Support

Questions don’t stop when the course ends.

Students receive technical support and can ask questions related to the course content and practical implementation.

Continuous Improvements

This course is continuously updated to reflect the latest ABB relay technologies, software releases, and engineering practices.

Your feedback helps shape future improvements and new content.

Enroll Today

Take your ABB relay engineering skills to the next level with one of the most comprehensive PCM600 training programs available online.

Lifetime Access • Practical Examples • Technical Support • Future Updates Included

Learn ABB PCM600 from installation to advanced relay configuration. Master IEC 61850, GOOSE, reports, disturbance records, protection functions, and ABB IED engineering with practical hands-on training.
