PSCAD Training for protection engineers

Completed

PSCAD Training for protection engineers

Aug 20, 2021 Fatima

PSCAD is the abbreviation for Power systems computer-aided design which is used to design and simulate power systems. The master library in the PSCAD contains many molding of the electrical power system which we use in our projects. This package Includes collected videos from different resources that save you a lot of time.

  • Language: English
  • Total length: 4 hrs
  • Format: Recorded Video
  • Trainer: Dr. Saeed Roostaee (Profile on Linkedin)
  • The training link and activation code will be sent to your email immediately after payment

Pack Details:

Part 1 (40 min, 4 sections):

  • Simulation of a simple three-phase AC system.
  • Different elements and their parameters are explained in detail.

Part 2 (41 min, 4 sections):

  • Distance protection scheme in detail

Part 3 (32 mins, 2 sections):

  • The Digital fault recorder in PSCAD and how to config the recorded signals in a fault analysis tool (SIGRA).

Part 4 (16 min, 2 sections):

  • several relay study cases

Part 5 (92 min, 5 sections):

  • The impedance-based fault location function and how to test this function in a relay
  • Both single end and double end methods, and the process of testing this function by using PSCAD, SIGRA
  • An experimental study has been carried out where several faults in different locations are simulated in PSCAD, The Comtrade file of each is loaded in the Omicron test universe and the associated voltage and current are injected into the SEL 421 (Distance relay) to test the relay fault location.

To know more info, and get the course please text on WhatsApp: +989129613659

Other Completed pieces of training:

Completed

DIGSI 4 Training

Oct 22, 2020 Fatima

SIPROTEC 4 devices will parameterize and operate via DIGSI 4 software. SIPROTEC 4 is considered the standard for numerical protection systems in all fields of application. The SIPROTEC 4 device series implements the integration of protection, control, measuring, and automation functions optimally in one device.

The materials of the DIGSI 4 course are designed to help you be a professional in this field. Nothing beats hands-on learning from an engaging instructor who gives you the necessary information.

In the field of power system protection, new IEDs are available now with high capability and advanced functions. Working with such devices needs special training and most universities do not cover such topics.

But why Protection relay?

We provide online and pre-recorded videos in the field of power system protection and substation automation systems. So you can be updated in the field by our training packages wherever and whenever you are. You have lifetime access to files.

DIGSI 4 Online Training

Overview:

  • Part 1: How to install DIGSI 4 (Length 01:57)
  • Part 2: Introduction to SIPROTEC Relay Families (Length 06:50)
  • Part 3: Wiring Connection (Length 03:02)
  • Part 4: Start with DIGSI (Length 19:12)
  • Part 5: Archive, Export, Import (Length 12:36)
  • Part 6: Masking I/O (Length 11:00)
  • Part 7: Masking I/O (Length 04:51)
  • Part 8: Masking I/O (Length 13:08)
  • Part 9: Default and Control Display (Length 16:21)
  • Part 10: CFC (Length 11:57)
  • Part 11: CFC and Implementation of experimental example (Length 07:59)
  • Part 12: CFC Interlocking Example (Length 04:26)
  • Part 13: CFC Protection Example (Length 04:13)
  • Part 14: CFC Explanation of all blocks (Length 11:01)
  • Part 15: Power system data 1 (Length 08:34)
  • Part 16: Setting Group (Length 19:13)
  • Part 17: Oscillographic Fault Recorders (Length 03:06)
  • Part 18: General Device Settings (Length 04:39)
  • Part 19: Time Synchronization and Interfaces (Length 03:40)
  • Part 20: Device Driver and Firmware Update (Length 09:04)
  • Part 21: Config SIPROTEC relay in a Practical Project (Length 14:36)

DIGSI 4 video training demo:

Contact us for more information and download:

Our Other Completed pieces of training:

Completed

IEC 61850 Configurator Training

Mar 2, 2020 Saeed

IEC-61850 is a protocol for the substation automation system. This protocol has capabilities that partially overcome the limitations of the automation system. This course is 4 hrs of main training.

Course Items:

  • Substation Automation – an overview
  • An introduction to IEC 61850 & how to learn it effectively
  • Overview of the main features of IEC 61850 – Part I
  • Overview of the main features of IEC 61850 – Part II
  • IEC 61850 data structure and data format – Part I
  • IEC 61850 data structure and data format – Part II
  • IEC 61850 station in DIGSI 5 and IEC 61850 System Configurator
  • GOOSE configuration and the publisher/subscriber LNs
  • GOOSE simulation via IEDScout
  • GOOSE configuration and simulation between SIP 5 & SEL relays
  • Time synchronization settings and SNTP configuration
  • Case study – Part I
  • Case study – Part II
  • Case study – Part III
  • IEC 61850 configuration in DIGSI 4
  • IEC 61850 configuration between SIP 4 & SIP 5
  • Sample project

Contact us for more information and download:

Demo Videos:
